TIS TISMFTECO Multifunction Tester with Accurate and Reliable 2 Wire Loop Test

Description

Multifunction Tester with Accurate and Reliable 2 Wire Loop Test

TISMFTECO

  • 2* & 3 wire loop tests
  • Accurate & Reliable "No Trip" testing
  • Line / Loop Impedance tests
  • Phase-Phase, Phase-Neutral, Phase-PE with 2 wire mode
  • TRMS for accurate measurements on noisy and distorted circuits
  • LPE/LN with PFC/PSC results displayed on a single test
  • New Auto Start Mode "on" or "off" for easy testing
  • Dual test buttons for left or right handed use
  • Phase to Phase Loop Test
  • Full help schematic display
  • Large COG graphic LCD display (128x128 pixels)
  • Compliant with BSEN 61557-12-3-4-5-6-7 18th Edition
  • RCD testing 6mA to 1A
  • Automatic RCD test, 0°, 180° x 1 x 5 x ½ with ramp & contact voltage tests
  • Auto mode for loop & rcd tests in a single test
  • Tripping of general, selective RCD's A, AC, B and 6mA RDC-DD for EVSE Charging Station
  • Continuity Test of earth conductors with test current >200mA
  • Phase Sequence Measurement
  • Insulation test at 50, 100, 250, 500 & 1000V
  • Safety compliance with IEC EN 61010-1
  • Built in pass / fail levels
  • Automatic testing of 3 insulation tests from one connection
  • Measurement Category CAT IV 300V

TIS TISMFTECO Multifunction Tester offers reliable and accurate 2 wire loop testing, measuring line and loop impedance, and TRMS for measurement on noisy and distorted circuits. It also features a new Auto Start Mode, dual test buttons for left or right handed use, phase to phase loop test, and large COG graphic LCD display. Compliant with BSEN 61557-12-3-4-5-6-7 18th Edition, it is equipped to perform RCD testing from 6mA to 1A with automatic RCD test, 0°, 180° x 1 x 5 x ½ with ramp & contact voltage tests, and auto mode for loop & RCD tests in a single test. Get the most out of your TIS TISMFTECO Multifunction Tester today!



.

Brand Test Instrument Solutions
Batteries Included
 Yes
Battery Level Indicator
 Yes
Battery Size AA
Colour Red/Black
Display Type LCD
Guarantee 3 Years
IP Rating IP40
Insulation Test Voltage 50V/100V/500V/1000V
RCD Settings
½ / x1 / x5 @ 0° and 180° / Auto and Ramp Tests
RCD Test Range 10 mA / 30 mA / 100 mA / 300 mA / 500 mA / 1000 mA
Safety Range CAT III 600V, CAT IV 300V
Standards
BS EN 61557-1-2-3-4-5-6-7 18th Edition

Read more

TIS TISMFTECO Multifunction Tester with Accurate and Reliable 2 Wire Loop Test

Product form

SKU: TISMFTECO

Multifunction Tester with Accurate and Reliable 2 Wire Loop Test TISMFTECO  2* & 3 wire loop tests Accurate & Reliable... Read more

£613.37 ex VAT £736.04 inc VAT

Available 1 - 2 working days

    • Guaranteed secure & safe checkout.

      shop pay
    • Free shipping on all orders above £100 + vat
      Specification

    Brand Test Instrument Solutions
    Batteries Included
    		 Yes
    Battery Level Indicator
    		 Yes
    Battery Size AA
    Colour Red/Black
    Display Type LCD
    Guarantee 3 Years
    IP Rating IP40
    Insulation Test Voltage 50V/100V/500V/1000V
    RCD Settings
    ½ / x1 / x5 @ 0° and 180° / Auto and Ramp Tests
    RCD Test Range 10 mA / 30 mA / 100 mA / 300 mA / 500 mA / 1000 mA
    Safety Range CAT III 600V, CAT IV 300V
    Standards
    BS EN 61557-1-2-3-4-5-6-7 18th Edition
      Downloads
    Datasheet unavailable for this product at the moment.

    Description

    Multifunction Tester with Accurate and Reliable 2 Wire Loop Test

    TISMFTECO

    • 2* & 3 wire loop tests
    • Accurate & Reliable "No Trip" testing
    • Line / Loop Impedance tests
    • Phase-Phase, Phase-Neutral, Phase-PE with 2 wire mode
    • TRMS for accurate measurements on noisy and distorted circuits
    • LPE/LN with PFC/PSC results displayed on a single test
    • New Auto Start Mode "on" or "off" for easy testing
    • Dual test buttons for left or right handed use
    • Phase to Phase Loop Test
    • Full help schematic display
    • Large COG graphic LCD display (128x128 pixels)
    • Compliant with BSEN 61557-12-3-4-5-6-7 18th Edition
    • RCD testing 6mA to 1A
    • Automatic RCD test, 0°, 180° x 1 x 5 x ½ with ramp & contact voltage tests
    • Auto mode for loop & rcd tests in a single test
    • Tripping of general, selective RCD's A, AC, B and 6mA RDC-DD for EVSE Charging Station
    • Continuity Test of earth conductors with test current >200mA
    • Phase Sequence Measurement
    • Insulation test at 50, 100, 250, 500 & 1000V
    • Safety compliance with IEC EN 61010-1
    • Built in pass / fail levels
    • Automatic testing of 3 insulation tests from one connection
    • Measurement Category CAT IV 300V

    TIS TISMFTECO Multifunction Tester offers reliable and accurate 2 wire loop testing, measuring line and loop impedance, and TRMS for measurement on noisy and distorted circuits. It also features a new Auto Start Mode, dual test buttons for left or right handed use, phase to phase loop test, and large COG graphic LCD display. Compliant with BSEN 61557-12-3-4-5-6-7 18th Edition, it is equipped to perform RCD testing from 6mA to 1A with automatic RCD test, 0°, 180° x 1 x 5 x ½ with ramp & contact voltage tests, and auto mode for loop & RCD tests in a single test. Get the most out of your TIS TISMFTECO Multifunction Tester today!



    .

    Brand Test Instrument Solutions
    Batteries Included
    		 Yes
    Battery Level Indicator
    		 Yes
    Battery Size AA
    Colour Red/Black
    Display Type LCD
    Guarantee 3 Years
    IP Rating IP40
    Insulation Test Voltage 50V/100V/500V/1000V
    RCD Settings
    ½ / x1 / x5 @ 0° and 180° / Auto and Ramp Tests
    RCD Test Range 10 mA / 30 mA / 100 mA / 300 mA / 500 mA / 1000 mA
    Safety Range CAT III 600V, CAT IV 300V
    Standards
    BS EN 61557-1-2-3-4-5-6-7 18th Edition
